40mn2 SAE1541 Alloy Seamless Pipe
40mn2 SAE1541 alloy seamless pipeSpecification NameSAE1541/40Mn2 cold drawn seamless carbon steel pipeStandardASTM, DIN,GBOD14mm*16mm-90mm*103mm or as your requirementWT0.15mm - 30mm or as your requirementLength0.5m-- 8m or as customers' request a) Outer Diameter: /- 0.2mmToleranceb) Thickness:......
Send Inquiry
Product Description
40mn2 SAE1541 alloy seamless pipe
Specification
Below is our stock items specification:
Specification
Name | SAE1541/40Mn2 cold drawn seamless carbon steel pipe |
Standard | ASTM, DIN,GB |
OD | 14mm*16mm-90mm*103mm or as your requirement |
WT | 0.15mm - 30mm or as your requirement |
Length | 0.5m-- 8m or as customers' request |
a) Outer Diameter: /- 0.2mm | |
Tolerance | b) Thickness: /- 0.02mm |
c) Length: /- 5mm | |
Surface | Oiled,Brightness |
Packing: | Export sea worthy package |
Delivery: | 5~30 days after payment |
MOQ: | 1Metric Ton/Metric Tons |
Price terms: | FOB, CFR, CIF |
Payment terms: | T/T, L/C |
Application | Precision machine parts,parts for car,auto and motorcycle,sleeve pipe |
Quality control: | a)Mill Test Certificate is supplied with shipment. b)Third party inspection is acceptable |
Advantage | a) Strong processing and warehousing service b) Stock available c) Strict quality control |
Below is our stock items specification:
| DESCRIPTION OF THE GOODS: COLD DRAWN SEAMLESS CARBON STEEL PIPE GRADE SAE1541,FINISH CONDITION NBK | ||||||||||
| ITEM | SIZE | MATERIAL | LENGTH | QTY | QTY | |||||
| OD mm | TOL. mm | ID mm | TOL. mm | MM | PCS | TONS | ||||
| 1 | 69.9 | ±0.2 | 60 | ±0.2 | SAE 1541/40MN2 | 3055 | 316 | 7.586 | ||
| 2 | 88.9 | ±0.2 | 77.8 | ±0.2 | SAE 1541/40MN2 | 3055 | 729 | 25.998 | ||
| 3 | 114.3 | ±0.2 | 101.6 | ±0.2 | SAE 1541/40MN2 | 3090 | 66 | 3.552 | ||
| TOTAL | 1111 | 37.136 | ||||||||
| REMARK: 40MN2 is equivalent of SAE 1541 | ||||||||||
| Chemical composition | ||||||||||
| MATERIAL | C | Si | Mn | P | S | Cr | Ni | Cu | ||
| 40MN2 | 0.37-0.44 | 0.17-0.37 | 1.40-1.80 | Max 0.035 | Max 0.035 | Max 0.3 | Max 0.3 | Max 0.2 | ||
