AISI 1010 Cold Drawn Seamless Steel Pipe
Carbon seamless steel pipeStandard: GB3087, low and medium pressure boiler with seamless steel tubes and pipes, using GB / T8162 seamless steel tube for high pressure boiler, structure with seamless steel tube GB/T8163 -- conveying fluid with seamless steel tube ASME SA106, seamless carbon steel pip......
Send Inquiry
Product Description
Carbon seamless steel pipe
Standard: GB3087, low and medium pressure boiler with seamless steel tubes and pipes, using GB / T8162 seamless steel tube for high pressure boiler, structure with seamless steel tube GB/T8163 -- conveying fluid with seamless steel tube ASME SA106, seamless carbon steel pipe for High-Temperature Service ASTM A106, seamless carbon steel pipe for High-Temperature service mainly in the production of steel pipe grades: 10, 20, 20g, SA106B, sa106c cast and A106B, A106C
Mechanical Property:
Chemical Composition:
Cold rolled precision seamless steel pipe
In order to obtain smaller size and better quality of seamless tube, cold rolling, cold drawing method must be used or combined. Cold rolling is usually in two roller mill, steel tube in variable cross section circular groove and immobility of the tapered plug is composed of an annular groove rolling. Cold drawing was usually in the 0.5 ~ 100T single chain or double chain drawbench.
Quality carbon structural steel cold dial seamless, with 10, 20, 35, 45 steel manufacturing, in addition to guarantee the chemical composition and mechanical properties to do pressure test, curling, expansion port, squash and other tests.
Formula weight: cold drawn seamless steel tube (diameter - thickness) * wall thickness of *0.02466=kg/ meters (weight per meter)
According to GB/ T3639-2009 (cold drawn or cold rolled precision seamless steel tube) commonly used standard size table:
Standard: GB3087, low and medium pressure boiler with seamless steel tubes and pipes, using GB / T8162 seamless steel tube for high pressure boiler, structure with seamless steel tube GB/T8163 -- conveying fluid with seamless steel tube ASME SA106, seamless carbon steel pipe for High-Temperature Service ASTM A106, seamless carbon steel pipe for High-Temperature service mainly in the production of steel pipe grades: 10, 20, 20g, SA106B, sa106c cast and A106B, A106C
| Standard | Grade | Tensile Strength(MPa) | Yield Strength(MPa) | Elongation(%) | Impact power(J) |
| GB3087 | 10 | 335~475 | ≥195 | ≥24 | |
| 20 | 410~550 | ≥245 | ≥20 | ||
| GB5310 | 20G | 410~550 | ≥245 | ≥24 | ≥35 |
| GB/T8162 | 10 | 335 | 185~205 | 24 | |
| 20 | 390 | 225~245 | 20 | ||
| 35 | 510 | 285~305 | 17 | ||
| 45 | 590 | 315~335 | 14 | ||
| Q345 | 490 | 305~325 | 21 | ||
| GB/T8163 | 10 | 335~475 | 195~205 | 24 | |
| 20 | 410~550 | 235~245 | 20 | ||
| Q295 | 430~610 | 285~295 | 22 | ||
| Q345 | 490~665 | 315~325 | 21 | ||
| ASME SA106 | SA106B | ≥415 | ≥240 | ≥22 | ≥35 |
| SA106C | ≥485 | ≥275 | ≥20 | ≥35 | |
| ASTM A106 | A106 Gr.A | ≥330 | ≥205 | 35 Longitudinal | |
| 25 Transverse | |||||
| A106 Gr.B | ≥415 | ≥240 | 30 Longitudinal | ||
| 16.5 Transverse | |||||
| A106 Gr.C | ≥485 | ≥275 | 30 Longitudinal | ||
| 16.5 Transverse |
Mechanical Property:
Standard | Grade | Chemical Composition(%) | ||||
| C | Si | Mn | P | S | ||
| GB3087 | 10 | 0.07~0.13 | 0.17~0.37 | 0.38~0.65 | ≤0.030 | ≤0.030 |
| 20 | 0.17~0.23 | 0.17~0.37 | 0.38~0.65 | ≤0.030 | ≤0.030 | |
| GB5310 | 20G | 0.17~0.24 | 0.17~0.37 | 0.35~0.65 | ≤0.030 | ≤0.030 |
| ASME SA106 | SA106B | 0.17~0.25 | ≥0.1 | 0.70~1.00 | ≤0.030 | ≤0.030 |
| ASTM A106 | A106 Gr.A | ≤0.25 | ≤0.10 | 0.27~0.93 | ≤0.035 | ≤0.035 |
| A106 Gr.B | ≤0.30 | ≤0.10 | 0.29~1.06 | ≤0.035 | ≤0.035 | |
| A106 Gr.C | ≤0.35 | ≤0.10 | 0.29~1.06 | ≤0.035 | ≤0.035 | |
| Standard | Grade | Chemical Composition(%) | ||||
| Cr | Mo | Cu | Ni | V | ||
| GB3087 | 10 | 0.3~0.65 | / | ≤0.25 | ≤0.30 | / |
| 20 | 0.3~0.65 | / | ≤0.25 | ≤0.30 | / | |
| GB5310 | 20G | ≤0.25 | ≤0.15 | ≤0.20 | ≤0.25 | ≤0.08 |
| ASME SA106 | SA106B | ≤0.035 | ||||
| ASTM A106 | A106 Gr.A | ≤0.40 | ≤0.15 | ≤0.40 | ≤0.40 | ≤0.08 |
| A106 Gr.B | ≤0.40 | ≤0.15 | ≤0.40 | ≤0.40 | ≤0.08 | |
| A106 Gr.C | ≤0.40 | ≤0.15 | ≤0.40 | ≤0.40 | ≤0.08 | |
Chemical Composition:
Cold rolled precision seamless steel pipe
In order to obtain smaller size and better quality of seamless tube, cold rolling, cold drawing method must be used or combined. Cold rolling is usually in two roller mill, steel tube in variable cross section circular groove and immobility of the tapered plug is composed of an annular groove rolling. Cold drawing was usually in the 0.5 ~ 100T single chain or double chain drawbench.
Quality carbon structural steel cold dial seamless, with 10, 20, 35, 45 steel manufacturing, in addition to guarantee the chemical composition and mechanical properties to do pressure test, curling, expansion port, squash and other tests.
Formula weight: cold drawn seamless steel tube (diameter - thickness) * wall thickness of *0.02466=kg/ meters (weight per meter)
According to GB/ T3639-2009 (cold drawn or cold rolled precision seamless steel tube) commonly used standard size table:
| OD*WT(mm) | OD*WT(mm) | OD*WT(mm) | OD*WT(mm) | OD*WT(mm) | OD*WT(mm) | OD*WT(mm) | OD*WT(mm) | OD*WT(mm) |
| Φ4×0.5 | Φ16×0.5 | Φ26×1.8 | Φ35×9.0 | Φ48×5.0 | Φ70×2.8 | Φ90×10 | Φ130×14 | Φ190×14 |
| Φ4×0.8 | Φ16×0.8 | Φ26×2.0 | Φ35×10 | Φ48×5.5 | Φ70×3.0 | Φ90×12 | Φ130×16 | Φ190×16 |
| Φ4×1.0 | Φ16×1.0 | Φ26×2.2 | Φ38×0.5 | Φ48×6.0 | Φ70×3.5 | Φ90×14 | Φ130×18 | Φ190×18 |
| Φ4×1.2 | Φ16×1.2 | Φ26×2.5 | Φ38×0.8 | Φ48×7.0 | Φ70×4.0 | Φ90×16 | Φ140×2.5 | Φ190×20 |
| Φ5×0.5 | Φ16×1.5 | Φ26×2.8 | Φ38×1.0 | Φ48×8.0 | Φ70×4.5 | Φ95×2.0 | Φ140×2.8 | Φ190×22 |
| Φ5×0.8 | Φ16×1.8 | Φ26×3.0 | Φ38×1.2 | Φ48×9.0 | Φ70×5.0 | Φ95×2.2 | Φ140×3.0 | Φ200×3.5 |
| Φ5×1.0 | Φ16×2.0 | Φ26×3.5 | Φ38×1.5 | Φ48×10 | Φ70×5.5 | Φ95×2.5 | Φ140×3.5 | Φ200×4.0 |
| Φ5×1.2 | Φ16×2.2 | Φ26×4.0 | Φ38×1.8 | Φ50×1.0 | Φ70×6.0 | Φ95×2.8 | Φ140×4.0 | Φ200×4.5 |
| Φ6×0.5 | Φ16×2.5 | Φ26×4.5 | Φ38×2.0 | Φ50×1.2 | Φ70×7.0 | Φ95×3.0 | Φ140×4.5 | Φ200×5.0 |
| Φ6×0.8 | Φ16×2.8 | Φ26×5.0 | Φ38×2.2 | Φ50×1.5 | Φ70×8.0 | Φ95×3.5 | Φ140×5.0 | Φ200×5.5 |
| Φ6×1.0 | Φ16×3.0 | Φ26×5.5 | Φ38×2.5 | Φ50×1.8 | Φ70×9.0 | Φ95×4.0 | Φ140×5.5 | Φ200×6.0 |
| Φ6×1.2 | Φ16×3.5 | Φ26×6.0 | Φ38×2.8 | Φ50×2.0 | Φ70×10 | Φ95×4.5 | Φ140×6.0 | Φ200×7.0 |
| Φ6×1.5 | Φ16×4.0 | Φ26×7.0 | Φ38×3.0 | Φ50×2.2 | Φ70×12 | Φ95×5.0 | Φ140×7.0 | Φ200×8.0 |
| Φ6×1.8 | Φ16×4.5 | Φ26×8.0 | Φ38×3.5 | Φ50×2.5 | Φ70×14 | Φ95×5.5 | Φ140×8.0 | Φ200×9.0 |
| Φ6×2.0 | Φ16×5.0 | Φ28×0.5 | Φ38×4.0 | Φ50×2.8 | Φ75×1.0 | Φ95×6.0 | Φ140×9.0 | Φ200×10 |
| Φ7×0.5 | Φ16×5.5 | Φ28×0.8 | Φ38×4.5 | Φ50×3.0 | Φ75×1.2 | Φ95×7.0 | Φ140×10 | Φ200×12 |
| Φ7×0.8 | Φ16×6.0 | Φ28×1.0 | Φ38×5.0 | Φ50×3.5 | Φ75×1.5 | Φ95×8.0 | Φ140×12 | Φ200×14 |
| Φ7×1.0 | Φ18×0.5 | Φ28×1.2 | Φ38×5.5 | Φ50×4.0 | Φ75×1.8 | Φ95×9.0 | Φ140×14 | Φ200×16 |
| Φ7×1.2 | Φ18×0.8 | Φ28×1.5 | Φ38×6.0 | Φ50×4.5 | Φ75×2.0 | Φ95×10 | Φ140×16 | Φ200×18 |
| Φ7×1.5 | Φ18×1.0 | Φ28×1.8 | Φ38×7.0 | Φ50×5.0 | Φ75×2.2 | Φ95×12 | Φ140×18 | Φ200×20 |
| Φ7×1.8 | Φ18×1.2 | Φ28×2.0 | Φ38×8.0 | Φ50×5.5 | Φ75×2.5 | Φ95×14 | Φ150×3.0 | Φ200×22 |
| Φ7×2.0 | Φ18×1.5 | Φ28×2.2 | Φ38×9.0 | Φ50×6.0 | Φ75×2.8 | Φ95×16 | Φ150×3.5 | |
| Φ8×0.5 | Φ18×1.8 | Φ28×2.5 | Φ38×10 | Φ50×7.0 | Φ75×3.0 | Φ95×18 | Φ150×4.0 | |
| Φ8×0.8 | Φ18×2.0 | Φ28×2.8 | Φ40×0.5 | Φ50×8.0 | Φ75×3.5 | Φ100×2.0 | Φ150×4.5 | |
| Φ8×1.0 | Φ18×2.2 | Φ28×3.0 | Φ40×0.8 | Φ50×9.0 | Φ75×4.0 | Φ100×2.2 | Φ150×5.0 | |
| Φ8×1.2 | Φ18×2.5 | Φ28×3.5 | Φ40×1.0 | Φ50×10 | Φ75×4.5 | Φ100×2.5 | Φ150×5.5 | |
| Φ8×1.5 | Φ18×2.8 | Φ28×4.0 | Φ40×1.2 | Φ55×1.0 | Φ75×5.0 | Φ100×2.8 | Φ150×6.0 | |
| Φ8×1.8 | Φ18×3.0 | Φ28×4.5 | Φ40×1.5 | Φ55×1.2 | Φ75×5.5 | Φ100×3.0 | Φ150×7.0 | |
| Φ8×2.0 | Φ18×3.5 | Φ28×5.0 | Φ40×1.8 | Φ55×1.5 | Φ75×6.0 | Φ100×3.5 | Φ150×8.0 | |
| Φ8×2.2 | Φ18×4.0 | Φ28×5.5 | Φ40×2.0 | Φ55×1.8 | Φ75×7.0 | Φ100×4.0 | Φ150×9.0 | |
| Φ8×2.5 | Φ18×4.5 | Φ28×6.0 | Φ40×2.2 | Φ55×2.0 | Φ75×8.0 | Φ100×4.5 | Φ150×10 | |
| Φ9×0.5 | Φ18×5.0 | Φ28×7.0 | Φ40×2.5 | Φ55×2.2 | Φ75×9.0 | Φ100×5.0 | Φ150×12 | |
| Φ9×0.8 | Φ18×5.5 | Φ28×8.0 | Φ40×2.8 | Φ55×2.5 | Φ75×10 | Φ100×5.5 | Φ150×14 | |
| Φ9×1.0 | Φ18×6.0 | Φ30×0.5 | Φ40×3.0 | Φ55×2.8 | Φ75×12 | Φ100×6.0 | Φ150×16 | |
| Φ9×1.2 | Φ20×0.5 | Φ30×0.8 | Φ40×3.5 | Φ55×3.0 | Φ75×14 | Φ100×7.0 | Φ150×18 | |
| Φ9×1.5 | Φ20×0.8 | Φ30×1.0 | Φ40×4.0 | Φ55×3.5 | Φ75×16 | Φ100×8.0 | Φ150×20 | |
| Φ9×1.8 | Φ20×1.0 | Φ30×1.2 | Φ40×4.5 | Φ55×4.0 | Φ80×1.0 | Φ100×9.0 | Φ160×3.0 | |
| Φ9×2.0 | Φ20×1.2 | Φ30×1.5 | Φ40×5.0 | Φ55×4.5 | Φ80×1.2 | Φ100×10 | Φ160×3.5 | |
| Φ9×2.2 | Φ20×1.5 | Φ30×1.8 | Φ40×5.5 | Φ55×5.0 | Φ80×1.5 | Φ100×12 | Φ160×4.0 | |
| Φ9×2.5 | Φ20×1.8 | Φ30×2.0 | Φ40×6.0 | Φ55×5.5 | Φ80×1.8 | Φ100×14 | Φ160×4.5 | |
| Φ9×2.8 | Φ20×2.0 | Φ30×2.2 | Φ40×7.0 | Φ55×6.0 | Φ80×2.0 | Φ100×16 | Φ160×5.0 | |
| Φ10×0.5 | Φ20×2.2 | Φ30×2.5 | Φ40×8.0 | Φ55×7.0 | Φ80×2.2 | Φ100×18 | Φ160×5.5 | |
| Φ10×0.8 | Φ20×2.5 | Φ30×2.8 | Φ40×9.0 | Φ55×8.0 | Φ80×2.5 | Φ110×2.0 | Φ160×6.0 | |
| Φ10×1.0 | Φ20×2.8 | Φ30×3.0 | Φ40×10 | Φ55×9.0 | Φ80×2.8 | Φ110×2.2 | Φ160×7.0 | |
| Φ10×1.2 | Φ20×3.0 | Φ30×3.5 | Φ42×1.0 | Φ55×10 | Φ80×3.0 | Φ110×2.5 | Φ160×8.0 | |
| Φ10×1.5 | Φ20×3.5 | Φ30×4.0 | Φ42×1.2 | Φ55×12 | Φ80×3.5 | Φ110×2.8 | Φ160×9.0 | |
| Φ10×1.8 | Φ20×4.0 | Φ30×4.5 | Φ42×1.5 | Φ60×1.0 | Φ80×4.0 | Φ110×3.0 | Φ160×10 | |
| Φ10×2.0 | Φ20×4.5 | Φ30×5.0 | Φ42×1.8 | Φ60×1.2 | Φ80×4.5 | Φ110×3.5 | Φ160×12 | |
| Φ10×2.2 | Φ20×5.0 | Φ30×5.5 | Φ42×2.0 | Φ60×1.5 | Φ80×5.0 | Φ110×4.0 | Φ160×14 | |
| Φ10×2.5 | Φ20×5.5 | Φ30×6.0 | Φ42×2.2 | Φ60×1.8 | Φ80×5.5 | Φ110×4.5 | Φ160×16 | |
| Φ10×2.8 | Φ20×6.0 | Φ30×7.0 | Φ42×2.5 | Φ60×2.0 | Φ80×6.0 | Φ110×5.0 | Φ160×18 | |
| Φ10×3.0 | Φ20×7.0 | Φ30×8.0 | Φ42×2.8 | Φ60×2.2 | Φ80×7.0 | Φ110×5.5 | Φ160×20 | |
| Φ12×0.5 | Φ22×0.5 | Φ30×9.0 | Φ42×3.0 | Φ60×2.5 | Φ80×8.0 | Φ110×6.0 | Φ170×3.0 | |
| Φ12×0.8 | Φ22×0.8 | Φ30×10 | Φ42×3.5 | Φ60×2.8 | Φ80×9.0 | Φ110×7.0 | Φ170×3.5 | |
| Φ12×1.0 | Φ22×1.0 | Φ32×0.5 | Φ42×4.0 | Φ60×3.0 | Φ80×10 | Φ110×8.0 | Φ170×4.0 | |
| Φ12×1.2 | Φ22×1.2 | Φ32×0.8 | Φ42×4.5 | Φ60×3.5 | Φ80×12 | Φ110×9.0 | Φ170×4.5 | |
| Φ12×1.5 | Φ22×1.5 | Φ32×1.0 | Φ42×5.0 | Φ60×4.0 | Φ80×14 | Φ110×10 | Φ170×5.0 | |
| Φ12×1.8 | Φ22×1.8 | Φ32×1.2 | Φ42×5.5 | Φ60×4.5 | Φ80×16 | Φ110×12 | Φ170×5.5 | |
| Φ12×2.0 | Φ22×2.0 | Φ32×1.5 | Φ42×6.0 | Φ60×5.0 | Φ85×1.5 | Φ110×14 | Φ170×6.0 | |
| Φ12×2.2 | Φ22×2.2 | Φ32×1.8 | Φ42×7.0 | Φ60×5.5 | Φ85×1.8 | Φ110×16 | Φ170×7.0 | |
| Φ12×2.5 | Φ22×2.5 | Φ32×2.0 | Φ42×8.0 | Φ60×6.0 | Φ85×2.0 | Φ110×18 | Φ170×8.0 | |
| Φ12×2.8 | Φ22×2.8 | Φ32×2.2 | Φ42×9.0 | Φ60×7.0 | Φ85×2.2 | Φ120×2.0 | Φ170×9.0 | |
| Φ12×3.0 | Φ22×3.0 | Φ32×2.5 | Φ42×10 | Φ60×8.0 | Φ85×2.5 | Φ120×2.2 | Φ170×10 | |
| Φ12×3.5 | Φ22×3.5 | Φ32×2.8 | Φ45×1.0 | Φ60×9.0 | Φ85×2.8 | Φ120×2.5 | Φ170×12 | |
| Φ12×4.0 | Φ22×4.0 | Φ32×3.0 | Φ45×1.2 | Φ60×10 | Φ85×3.0 | Φ120×2.8 | Φ170×14 | |
| Φ14×0.5 | Φ22×4.5 | Φ32×3.5 | Φ45×1.5 | Φ60×12 | Φ85×3.5 | Φ120×3.0 | Φ170×16 | |
| Φ14×0.8 | Φ22×5.0 | Φ32×4.0 | Φ45×1.8 | Φ65×1.0 | Φ85×4.0 | Φ120×3.5 | Φ170×18 | |
| Φ14×1.0 | Φ22×5.5 | Φ32×4.5 | Φ45×2.0 | Φ65×1.2 | Φ85×4.5 | Φ120×4.0 | Φ170×20 | |
| Φ14×1.2 | Φ22×6.0 | Φ32×5.0 | Φ45×2.2 | Φ65×1.5 | Φ85×5.0 | Φ120×4.5 | Φ180×3.5 | |
| Φ14×1.5 | Φ22×7.0 | Φ32×5.5 | Φ45×2.5 | Φ65×1.8 | Φ85×5.5 | Φ120×5.0 | Φ180×4.0 | |
| Φ14×1.8 | Φ25×0.5 | Φ32×6.0 | Φ45×2.8 | Φ65×2.0 | Φ85×6.0 | Φ120×5.5 | Φ180×4.5 | |
| Φ14×2.0 | Φ25×0.8 | Φ32×7.0 | Φ45×3.0 | Φ65×2.2 | Φ85×7.0 | Φ120×6.0 | Φ180×5.0 | |
| Φ14×2.2 | Φ25×1.0 | Φ32×8.0 | Φ45×3.5 | Φ65×2.5 | Φ85×8.0 | Φ120×7.0 | Φ180×5.5 | |
| Φ14×2.5 | Φ25×1.2 | Φ32×9.0 | Φ45×4.0 | Φ65×2.8 | Φ85×9.0 | Φ120×8.0 | Φ180×6.0 | |
| Φ14×2.8 | Φ25×1.5 | Φ32×10 | Φ45×4.5 | Φ65×3.0 | Φ85×10 | Φ120×9.0 | Φ180×7.0 | |
| Φ14×3.0 | Φ25×1.8 | Φ35×0.5 | Φ45×5.0 | Φ65×3.5 | Φ85×12 | Φ120×10 | Φ180×8.0 | |
| Φ14×3.5 | Φ25×2.0 | Φ35×0.8 | Φ45×5.5 | Φ65×4.0 | Φ85×14 | Φ120×12 | Φ180×9.0 | |
| Φ14×4.0 | Φ25×2.2 | Φ35×1.0 | Φ45×6.0 | Φ65×4.5 | Φ85×16 | Φ120×14 | Φ180×10 | |
| Φ14×4.5 | Φ25×2.5 | Φ35×1.2 | Φ45×7.0 | Φ65×5.0 | Φ90×1.5 | Φ120×16 | Φ180×12 | |
| Φ15×0.5 | Φ25×2.8 | Φ35×1.5 | Φ45×8.0 | Φ65×5.5 | Φ90×1.8 | Φ120×18 | Φ180×14 | |
| Φ15×0.8 | Φ25×3.0 | Φ35×1.8 | Φ45×9.0 | Φ65×6.0 | Φ90×2.0 | Φ130×2.5 | Φ180×16 | |
| Φ15×1.0 | Φ25×3.5 | Φ35×2.0 | Φ45×10 | Φ65×7.0 | Φ90×2.2 | Φ130×2.8 | Φ180×18 | |
| Φ15×1.2 | Φ25×4.0 | Φ35×2.2 | Φ48×1.0 | Φ65×8.0 | Φ90×2.5 | Φ130×3.0 | Φ180×20 | |
| Φ15×1.5 | Φ25×4.5 | Φ35×2.5 | Φ48×1.2 | Φ65×9.0 | Φ90×2.8 | Φ130×3.5 | Φ190×3.5 | |
| Φ15×1.8 | Φ25×5.0 | Φ35×2.8 | Φ48×1.5 | Φ65×10 | Φ90×3.0 | Φ130×4.0 | Φ190×4.0 | |
| Φ15×2.0 | Φ25×5.5 | Φ35×3.0 | Φ48×1.8 | Φ65×12 | Φ90×3.5 | Φ130×4.5 | Φ190×4.5 | |
| Φ15×2.2 | Φ25×6.0 | Φ35×3.5 | Φ48×2.0 | Φ65×14 | Φ90×4.0 | Φ130×5.0 | Φ190×5.0 | |
| Φ15×2.5 | Φ25×7.0 | Φ35×4.0 | Φ48×2.2 | Φ70×1.0 | Φ90×4.5 | Φ130×5.5 | Φ190×5.5 | |
| Φ15×2.8 | Φ25×8.0 | Φ35×4.5 | Φ48×2.5 | Φ70×1.2 | Φ90×5.0 | Φ130×6.0 | Φ190×6.0 | |
| Φ15×3.0 | Φ26×0.5 | Φ35×5.0 | Φ48×2.8 | Φ70×1.5 | Φ90×5.5 | Φ130×7.0 | Φ190×7.0 | |
| Φ15×3.5 | Φ26×0.8 | Φ35×5.5 | Φ48×3.0 | Φ70×1.8 | Φ90×6.0 | Φ130×8.0 | Φ190×8.0 | |
| Φ15×4.0 | Φ26×1.0 | Φ34×6.0 | Φ48×3.5 | Φ70×2.0 | Φ90×7.0 | Φ130×9.0 | Φ190×9.0 | |
| Φ15×4.5 | Φ26×1.2 | Φ35×7.0 | Φ48×4.0 | Φ70×2.2 | Φ90×8.0 | Φ130×10 | Φ190×10 | |
| Φ15×5.0 | Φ26×1.5 | Φ35×8.0 | Φ48×4.5 | Φ70×2.5 | Φ90×9.0 | Φ130×12 | Φ190×12 |
